Divinity – A High-Value Entry-Level DAC
Divinity is a mid-to-high-end R-2R DAC that achieves ultra-low distortion and background noise while preserving the original sampling rate. It features a fully balanced R-2R ladder network design (independent high-speed CPLD per channel), low-phase-noise oscillators, and full-digital input FIFO buffering with reclocking technology.
Its box-in-box power design, with a 1.5mm metal alloy casing, isolates the mainboard from the linear power supply. Combined with dual O-core transformers and multi-stage regulation, it enhances power purity. Upgrades include high-precision resistors, premium capacitors, and pure silver wiring. Supporting DSD and PCM up to 384kHz/32bit, Divinity is an ideal choice for music enthusiasts seeking high resolution and natural sound quality.
Core Technology
True Balanced R-2R Ladder Network
Each channel features an independent high-speed CPLD and four sets of 0.005% high-precision resistor networks, achieving ultra-low distortion and minimal background noise.
Low Phase-Noise Oscillator
Enhances clock stability and reduces dependence on source devices.
Full Digital Input Processing
FIFO buffering + onboard CPLD reclocking to suppress jitter, supporting DSD 256 and PCM 384kHz/32bit.
Supports Multiple Audio Input and Output Interfaces
Supported inputs: USB audio, OPT, COAX, AES, I2S-1, I2S-2 (HDMI port).
Supported outputs: 2 sets of XLR (balanced) and 2 sets of RCA (unbalanced), with separate left and right output channels.
menu
STANDBY
VOLUME/SELECT
INPUT/ ENTER
ANALOG OUT
POWER SUPPLY
DIGITAL IN
Power Design
Box-in-Box Structure: 1.5mm metal alloy casing isolates the mainboard from the power supply, reducing interference.
Linear Power Supply: Dual O-core transformers (separate for digital and analog), multi-stage regulation, and 22MF low-ESR capacitors.
Pure Silver Wiring: Upgraded power transmission wires enhance conductivity and signal purity.
The DIVINITY DAC features a volume knob on the decoder, eliminating the need for a preamplifier. This not only saves costs but also enhances convenience, making it a highly user-friendly choice for entry-level audiophiles.
Sound Performance
Non-Oversampling (NOS) Mode: Preserves the original sampling rate, minimizing digital processing loss. Natural Soundstage: Well-layered and rich in detail, ideal for complex music genres such as classical and jazz.
